T8423C is the conformal coated, extended temperature variant of the T8423, a Trusted TMR 120 VDC Digital Input Module for the Trusted T8000 Safety Instrumented System (SIS) by ICS Triplex / Rockwell Automation。

Description

1. Introduction

T8423C is the conformal coated, extended temperature variant of the T8423, a Trusted TMR 120 VDC Digital Input Module for the Trusted T8000 Safety Instrumented System (SIS) by ICS Triplex / Rockwell Automation
It provides 40 channels of 120 VDC digital input with Triple Modular Redundancy (TMR) and per‑channel 1oo2D voting, certified for IEC 61508 SIL 3 / SIL 4 safety applications。
  • Purpose: Monitor discrete 120 VDC field devices (switches, contactors, relay contacts)

  • Architecture: TMR (3‑2‑0) + 1oo2D per‑channel voting

  • Safety: IEC 61508 SIL 3 / SIL 4 certified

  • Coating: Acrylic conformal coating (humidity, dust, chemical resistance)

  • Temp Range: –40 °C to +70 °C (standard T8423: 0 °C to +60 °C)

  • Channels: 40 × 120 VDC digital inputs

  • Isolation: 2500 V DC optical (channel–channel, channel–system)

  • SOE: 1 ms resolution sequence‑of‑events logging

  • Hot‑Swap: Yes (online replacement)


2. Product Overview

The T8423C is a compact, 56 mm wide T8000 chassis module designed for 120 VDC field input monitoring in harsh industrial environments
  • 40 × 120 VDC digital input channels (sink/source configurable)

  • Fully triplicated (TMR) input processing (three independent measurement lanes)

  • Sigma‑delta ADCs for high‑precision voltage sampling

  • Per‑channel 1oo2D voting for fault detection

  • Optical isolation (2500 V DC) between field and backplane

  • Onboard SOE (1 ms) for event time‑stamping

  • Independent line monitoring (open/short circuit) per channel

  • Acrylic conformal coating for condensation, dust, and chemical resistance

  • Extended temperature range for extreme operating conditions

It mounts in T8100 / T8400 Trusted Controller Chassis and communicates via the Trusted Backplane Bus (TBB)

3. Specifications

3.1 Mechanical

  • Form Factor: T8000 chassis module, 56 mm wide, 6U

  • Dimensions (H×W×D): 255 mm × 56 mm × 210 mm

  • Weight: 1.3 kg (2.87 lbs)

  • Mounting: T8100 / T8400 chassis slots 1–16

  • Connectors: Front‑panel terminal blocks (TB1–TB5, 8 channels each)

  • PCB Protection: Acrylic conformal coating (T8423C)

3.2 Electrical

  • System Supply: 20–32 V DC (nominal 24 V DC)

  • Power Consumption: ≤ 5 W

  • Input Channels: 40 × 120 VDC digital inputs

  • Input Voltage Thresholds:

    • Logic 1: 90–150 V DC

    • Logic 0: <30 V DC

  • Input Current: ~4 mA per channel (at 120 V DC)

  • Input Type: Sink (NPN) / Source (PNP) configurable

  • Isolation: 2500 V DC optical barrier (channel–channel, channel–system)

  • Backplane Interface: Trusted Backplane Bus (TBB), TMR

3.3 Functional

  • Voting: 1oo2D per channel (triple measurement + comparison)

  • SOE Resolution: 1 ms (per channel state change)

  • Diagnostics:

    • Open‑circuit detection (per channel, with line resistor)

    • Short‑circuit detection (per channel)

    • Onboard BIST (Built‑In Self‑Test)

    • Fault logging to system HMI

  • Response Time: ≤ 2.0 ms (channel to backplane)

  • Data Integrity: BER < 10⁻¹²

3.4 Environmental (C‑version critical)

  • Operating Temperature: –40 °C to +70 °C

  • Storage Temperature: –40 °C to +85 °C

  • Humidity: 5–95 % RH, condensing tolerant

  • Altitude: ≤ 2000 m

  • Vibration: IEC 60068‑2‑6 (1 g, 10–150 Hz)

  • Shock: IEC 60068‑2‑27 (15 g, 11 ms)

3.5 Safety & Certification

  • Safety Standard: IEC 61508 SIL 3 / SIL 4

  • Certifications: CE, UL, CSA, ATEX II 3G Ex ec IIC T4 Gc, IECEx

  • Fault Tolerance: TMR (3‑2‑0), 1oo2D per channel

  • PFHd: < 8.0 × 10⁻¹⁰ / h (SIL 4)


4. Front Panel & Indicators

  • PWR (Green): On = Module power OK; Off = No power

  • RUN (Green): On = Module active; Flashing = Initialization / BIST

  • FAULT (Red): On = Module/channel fault; Flashing = Minor fault

  • COM (Green): Flashing = Backplane communication active

  • TB1–TB5: 5 × terminal blocks (8 channels each, 120 VDC inputs)

  • FG: Functional Ground (chassis earth)


5. Installation & Wiring

  • Chassis Mounting: Align with empty slot in T8100/T8400 chassis, insert firmly, tighten front‑panel screws (torque 0.8–1.0 Nm)

  • Field Wiring: For each terminal block, connect 120 VDC + to group common terminal, field device output to channel input terminal, device common to 0 VDC / GND

  • Wire Gauge: 16–22 AWG stranded wire; torque terminals to 0.5–0.6 Nm

  • Line Resistors: 10 kΩ for open‑circuit monitoring (per channel)

  • Hot‑Swap: Supported; system auto‑detects new module without shutdown


6. Operation & Diagnostics

  • Power‑up: PWR ON; RUN flashes during self‑test (5–10 s)

  • Normal Operation: PWR + RUN steady GREEN; FAULT OFF; COM flashing

  • Fault Conditions: FAULT ON = critical fault (channel short/open, TMR mismatch); FAULT Flashing = minor fault (single‑lane mismatch)

  • SOE Logging: All state changes time‑stamped (1 ms) and stored in system memory


7. Ordering Information

  • T8423: Standard 40‑Ch 120 VDC DI (0 °C … +60 °C)

  • T8423C: Conformal coated, –40 °C … +70 °C

  • TC‑8423: Terminal Block Cable Kit (field wiring)

  • T8100 / T8400: Trusted Controller Chassis
