• This appliance must be grounded. Connect only to a properly grounded 120V AC outlet.

• Consult a physician before starting any exercise program, especially if you have heart conditions, high blood pressure, joint pain, or are pregnant.

• Keep hands dry when operating controls. Never touch power switch or console with wet hands.

• Wear proper athletic shoes. Do not use barefoot, in socks, or with loose/open-toe footwear.

• Do not stand on the belt during startup. Always stand on side rails until belt reaches desired speed.

• Use the magnetic safety key. Clip it firmly to your clothing before exercising; the belt stops immediately if pulled out.

• Keep children and pets away during operation. Do not leave children unsupervised near the equipment.

• Do not use outdoors or in humid areas. Avoid rain, moisture, and prolonged direct sunlight.

• Do not place fingers near moving parts, rollers, or belt edges.

• Maximum user weight: 325 lbs (147 kg). Do not exceed this limit.

Features

• 3.0 HP Continuous-Duty Industrial Motor: Ultra-quiet, high-torque, built for long daily workouts.

• Motorized Incline (0–15%): One-touch electric incline for intense hill simulation.

• Premium Folding Frame with Hydraulic Assist: Easy lift, heavy‑duty safety lock, stable vertical storage.

• 10 Preset Console Programs: P1 Manual, P2 Interval, P3 Weight Loss, P4 Hill, P5 Cardio, P6 Endurance, P7 Fat Burn, P8 Speed, P9 Custom, P10 Heart Rate.

• High‑Contrast LED Console with Blue Backlight: Large digits, easy readout in all lighting; tracks Time, Distance, Speed, Calories, Incline, Heart Rate.

• Dual Heart Rate System: Contact handgrips + Bluetooth wireless chest strap compatible (optional).

• Running Surface: 22” W × 60” L commercial‑grade 2‑ply non‑slip belt.

• Soft Deck Pro Cushioning: Multi‑layer shock absorption reduces knee/ankle impact.

• Speed Range: 0.5–12 MPH (0.8–19.3 km/h) in 0.1 MPH precision increments.

• USB Charging Port: Charge phone/tablet during workouts.

• Max User Weight: 325 lbs (147 kg).

Assembly Instructions

1. Unpack all components: main base frame, console support uprights, console, magnetic safety key, power cord, hardware kit, user manual.

2. Place base frame on flat, level, sturdy floor. Attach console uprights to base using provided bolts and Allen wrench; tighten securely.

3. Connect console wiring harness to base connector; ensure firm fit and no loose wires.

4. Mount console onto support uprights and fasten with screws.

5. Insert magnetic safety key fully into console slot; clip other end firmly to workout clothing.

6. Plug power cord into dedicated 120V AC outlet; avoid extension cords or shared circuits.

Placement & Leveling

• Position on flat, solid floor. Avoid thick carpet that causes instability or blocks airflow.

• Adjust leveling feet on base until treadmill sits evenly with no wobble.

• Maintain at least 3 feet (1 meter) clearance around treadmill for safety, ventilation, and folding access.

• Do not place near heat sources, water, or direct sunlight.

• Keep rear area clear for emergency stop and folding operation.

Console Operation

Power On & Startup

• Insert safety key fully; console lights up and enters standby mode.

• Press START to begin; belt starts at 1 MPH (1.6 km/h) by default.

• Always stand on side rails during startup until belt reaches desired speed.

Program Selection

1. Press PROGRAM to cycle through 10 preset programs:

   • P1 Manual: Full user control of speed/incline at all times.

   • P2 Interval: 24‑minute high/low speed intervals for endurance.

   • P3 Weight Loss: 48‑minute gradual speed changes for steady calorie burn.

   • P4 Hill: 30‑minute automatic incline (2–15%) for leg strength.

   • P5 Cardio: 36‑minute steady‑state cardio for heart health.

   • P6 Endurance: 60‑minute moderate pace for stamina building.

   • P7 Fat Burn: Low‑moderate intensity to optimize fat metabolism.

   • P8 Speed: Progressive speed intervals for sprint training.

   • P9 Custom: Save and recall personal speed/incline profiles.

   • P10 Heart Rate: Target‑zone workout based on user heart rate.

2. Press LEVEL (1–10) to set difficulty for preset programs.

3. Press TIME to adjust workout duration (5–99 minutes).

4. Press START to confirm and begin selected program.

Adjusting Settings During Workout

• Speed: Press SPEED UP / DOWN arrows (0.5–12 MPH / 0.8–19.3 km/h); 0.1 MPH increments.

• Incline: Press INCLINE UP / DOWN (0–15% motorized).

• Pause: Press STOP once; belt stops, data holds. Press START to resume.

• Reset: Hold STOP for 3 seconds; clears data and returns to standby.

• Heart Rate: Hold handgrips firmly or use Bluetooth wireless chest strap.

• USB Charging: Connect device to USB port for power during exercise.

Program Descriptions

• P1 Manual: Fully customizable; adjust speed/incline anytime.

• P2 Interval: Improves speed and endurance with structured intervals.

• P3 Weight Loss: Optimized for steady calorie burn and fat reduction.

• P4 Hill: Builds leg strength and cardio capacity via steep inclines.

• P5 Cardio: Sustains target heart rate for efficient cardiovascular training.

• P6 Endurance: Long‑duration moderate workout to build stamina.

• P7 Fat Burn: Low‑intensity, extended workout for fat‑burning zone.

• P8 Speed: Progressive speed intervals to improve sprint performance.

• P9 Custom: Create and store personal workouts for quick recall.

• P10 Heart Rate: Automatically adjusts speed/incline to maintain target heart rate.

Folding & Storage

1. Ensure treadmill is turned off and unplugged.

2. Remove safety key.

3. Lift running deck upward using built‑in handle; hydraulic assist reduces lifting effort.

4. Push deck until it locks into vertical storage position.

5. Confirm safety lock is fully engaged before moving or storing.

6. To unfold: Release lock, lower deck slowly to floor position.

Maintenance

Cleaning

• Vacuum belt, side rails, and base weekly to remove dust and debris.

• Wipe console, belt, and frame with a slightly damp cloth after each use to remove sweat.

• Do not use solvents, harsh chemicals, or abrasive cleaners on belt or deck—they damage lubrication and surface materials.

• Dry all surfaces thoroughly after cleaning.

Belt Centering

1. Run treadmill at 3–4 MPH (4.8–6.4 km/h) with no user on belt.

2. If belt drifts left: Turn left rear roller bolt 1/4 turn clockwise.

3. If belt drifts right: Turn right rear roller bolt 1/4 turn clockwise.

4. Run 5 minutes to check alignment; repeat if needed (max 1/4 turn at a time).

Belt Tension

• If belt slips during walking/running: Tighten both rear roller bolts 1/4 turn clockwise evenly.

• Test and repeat if necessary. Do not over‑tighten—it shortens belt life and strains motor.

Deck & Motor Care

• Lubricate running deck every 3–6 months with manufacturer‑recommended silicone lubricant.

• Clean motor vents monthly to prevent dust buildup and overheating.

• Inspect wiring connections quarterly for fraying or loose wires.

• Check all frame bolts and hardware every 3 months; tighten if loose.

Troubleshooting

• No power to console: Safety key not inserted; power cord unplugged; outlet dead. Insert key, plug in, check outlet.

• Console lights but belt won’t move: Safety key not fully seated; belt too tight/loose; drive belt broken. Check key and tension; call service if motor hums.

• Belt slips: Loose belt or worn deck. Tighten belt; replace deck if slipping continues.

• Belt drifts: Adjust centering bolts per maintenance section.

• No incline response: Incline motor fault or loose wiring. Check wires; contact service.

• Unusual noise: Loose bolts, debris under belt, or worn bearings. Tighten hardware, clean under belt; call service if noise persists.

• Heart rate inaccurate: Grips dirty or hands dry. Clean grips; moisten hands slightly or use Bluetooth strap.

• Console shows error code: Unplug for 5 minutes, restart. If error returns, note code and contact customer service.

Specifications

• Motor: 3.0 HP continuous‑duty, industrial grade, quiet

• Speed Range: 0.5–12 MPH (0.8–19.3 km/h), 0.1 MPH increments

• Incline Range: 0–15% (motorized, one‑touch)

• Running Surface: 22” W × 60” L (55.9 cm × 152.4 cm)

• Assembled Dimensions: 74” L × 34” W × 54” H (188 cm × 86.4 cm × 137.2 cm)

• Folded Dimensions: 34” W × 74” H × 60” D (86.4 cm × 188 cm × 152.4 cm)

• Net Weight: 225 lbs (102 kg)

• Max User Weight: 325 lbs (147.4 kg)

• Power Requirement: 120V AC, 60Hz, 15A dedicated circuit
