CLIPSAL L5508D1A C-BUS 8-CHANNEL LEADING EDGE DIMMER MODULE

Clipsal L5508D1A is a DIN rail mounted 8-channel leading-edge dimmer module for Clipsal C-Bus intelligent lighting control system (Schneider Electric). This lighting dimming control board supports 240VAC input, 1A per channel, integrated C-Bus power supply. It executes brightness adjustment for incandescent lamps and low-voltage halogen lamps with electronic transformers, receiving command signals from C-Bus network and performing channel continuity monitoring. It has 3.75kV isolation between C-Bus low voltage circuit and mains circuit, LED channel status indicators and built-in self-diagnosis for fault detection. It is widely used for commercial building, vessel cabin and public area lighting automation.

This unit is a vital intelligent lighting automation spare part for lighting control cabinet overhaul. The lighting control spare part continuously regulates lamp brightness of 8 independent lighting channels. The lighting control spare part communicates with C-Bus network to receive on/off and dimming setpoint commands. The lighting control spare part can replace faulty dimmer module to restore multi-channel lighting dimming and sequence control.

It delivers reliable multi-channel lighting dimming & C-Bus network signal acquisition control for intelligent lighting systems. The multi-channel lighting dimming & C-Bus network signal acquisition control adjusts output voltage to modify lamp brightness via leading-edge phase cutting. The multi-channel lighting dimming & C-Bus network signal acquisition control provides galvanic isolation to protect C-Bus backplane from mains voltage transients. The multi-channel lighting dimming & C-Bus network signal acquisition control supports scene recall, timer logic and lamp fault alarm handling for building automation.

L5508D1A module is DIN rail mounted inside C-Bus control cabinet. It is original Clipsal spare part for C-Bus intelligent lighting control system maintenance.
