JRCS LCU-TM15-R TM15-L MARINE TANK GAUGING DUAL INTERFACE PCB

JRCS LCU-TM15-R (TM15-L) is a rugged paired left/right channel interface PCB card for JRCS LMS series marine liquid cargo tank gauging automation system onboard oil tankers. This tank measuring interface board collects analog 4-20mA signals from tank radar level, pressure and temperature transmitters, performs signal conditioning, EMI filtering and serial fieldbus communication. The L version and R version work together as matched pair to transmit multi-tank measuring data to vessel operator workstation and loading computer. This PCB adopts conformal coating to resist salt mist, vibration and high humidity inside marine instrument cabinet, with individual channel LED status indicators for fault diagnosis.

This unit is a vital marine tank gauging spare part for tanker control cabinet overhaul. The marine tank gauging spare part continuously samples multiple cargo tank measuring points including ullage, temperature and pressure. The marine tank gauging spare part transmits real-time tank data and high/low level alarm signals to vessel automation system. The marine tank gauging spare part can replace faulty paired PCB to restore accurate tank measurement and cargo monitoring.

It delivers reliable multi-channel tank signal acquisition & fieldbus data transmission control for marine cargo monitoring systems. The multi-channel tank signal acquisition & fieldbus data transmission control provides galvanic isolation to protect backplane rack from field circuit voltage transients. The multi-channel tank signal acquisition & fieldbus data transmission control filters power line interference to guarantee stable measurement accuracy under vessel vibration. The multi-channel tank signal acquisition & fieldbus data transmission control logs timestamped alarm events for marine survey inspection and maintenance troubleshooting.

LCU-TM15-R / TM15-L PCB is rack-mounted inside JRCS LMS tank gauging control rack. It is original JRCS spare part for legacy tanker cargo tank monitoring system maintenance.
