ROSEMOUNT 5302HA1H1N4AE00600EBE5M1 Product Description

The ROSEMOUNT 5302HA1H1N4AE00600EBE5M1 is a high-precision guided wave radar transmitter engineered for liquid level and liquid interface measurement within industrial process vessels. This guided wave radar transmitter adopts time-domain reflectometry principle to emit low-power nanosecond microwave pulses along the probe, capturing reflected signals to calculate medium height without being affected by temperature, pressure, steam or foam interference. This guided wave radar transmitter features patented Direct Switch Technology, greatly improving signal sensitivity for low dielectric fluids and viscous slurries in tough working conditions. This guided wave radar transmitter supports simultaneous level and interface detection, helping operators monitor layered media inside separators, storage tanks and process reactors with stable and repeatable readings.

This ROSEMOUNT model delivers outstanding measuring accuracy and strong anti-interference ability for continuous tank monitoring. Its durable radar level probe transmits microwave signals steadily through liquid and vapor layers, maintaining stable signal transmission even in high-pressure and high-temperature environments. The radar level probe is available with multiple wetted material selections to resist corrosion from acids, alkalis and various chemical media in oil & gas, chemical and power industries. On-site installation of the radar level probe is simple, and the probe can be customized to match different tank heights and vessel connection types. The reliable structure of the radar level probe reduces mechanical failure risks and extends service life under long-term continuous operation.

The transmitter is equipped with rich intelligent diagnostic functions and meets IEC 61508 SIL 2 safety certification for safety instrumented systems. Precise tank level monitoring tracks real-time liquid height and interface boundary to prevent tank overflow and empty tank risks during production. Stable tank level monitoring provides continuous digital data for DCS and PLC control systems, supporting automatic feeding and discharge control. Predictive maintenance alerts from tank level monitoring help engineers discover probe fouling or signal abnormality at an early stage before measurement deviation appears. Accurate tank level monitoring optimizes inventory management, reduces material waste and improves overall plant operational efficiency.

The ROSEMOUNT 5302HA1H1N4AE00600EBE5M1 supports 4-20mA HART communication protocol, allowing convenient configuration, parameter adjustment and data reading via handheld communicators or asset management software. It features Type 4X, IP66 and IP67 enclosure protection to resist dust, moisture and harsh outdoor environments. The device can work normally under wide pressure and temperature ranges, and dynamic vapor compensation function guarantees measurement precision even in saturated steam environments. EchoLogics signal processing algorithm filters false echoes caused by tank internal obstacles, eliminating misreading and enhancing measurement reliability. It can be directly retrofitted into existing stilling chambers or matched with complete chamber assemblies, shortening project construction and commissioning cycles. Widely applied in oil-water separators, product storage tanks, chemical reactors and pulp processing vessels, this ROSEMOUNT guided wave radar transmitter is a trusted solution for demanding liquid level and interface measurement projects globally.
