Schneider Electric TSXDEF812 Product Description

Schneider Electric TSXDEF812 is a classic isolated digital input module for Modicon TSX Micro PLC automation systems. This isolated digital input module provides 8 channels of 24V DC isolated discrete input to collect field sensor and limit switch signals. The compact isolated digital input module can be directly inserted onto TSX Micro CPU rack for I/O expansion. This isolated digital input module transmits field on/off signals to PLC for sequence control and alarm interlock.

TSXDEF812 delivers reliable galvanic isolated signal acquisition to separate field side and PLC internal logic circuit. Accurate galvanic isolated signal acquisition blocks surge and interference from field wiring. Stable galvanic isolated signal acquisition prevents module damage caused by ground potential difference. Dependable galvanic isolated signal acquisition reduces PLC false triggering in harsh workshop environments.

This unit features integrated channel status indicator to display each input channel signal status in real time. The intuitive integrated channel status indicator helps engineers quickly judge wiring and signal faults. The high-reliability integrated channel status indicator simplifies cabinet debugging and routine inspection. This durable integrated channel status indicator supports long-time continuous cyclic operation.

Schneider Electric TSXDEF812 is widely applied in packaging machinery, conveyor systems, machine tools and water treatment control cabinets. It adopts standard screw terminal design for convenient wiring and fast spare replacement. It is discontinued original spare part for maintenance and retrofit of legacy TSX Micro PLC systems.
