SE3007 KJ2005X1-BK1 | Emerson DeltaV SX Controller
Product Introduction
SE3007(KJ2005X1-BK1,alternate PN:12P4688X032/12P4688X042) belongs to Emerson DeltaV SX high-performance rack-mounted controller, core control unit of S-series DeltaV DCS platform. It undertakes loop PID regulation, interlock logic, batch sequence control and field I/O data acquisition, compatible with legacy SD/SQ controller program configuration, supports 1+1 redundant hot backup for uninterrupted industrial production control. SE prefix stands for S-series rack controller, interchangeable with VE3007 SX version in system configuration.
Description
Part Code Definition
SE3007：DeltaV SX series controller model codeKJ2005X1-BK1：official Emerson ordering part number & hardware revision identifier12P4688X032/12P4688X042：factory alternative spare part number
Technical Specifications
Processor: Industrial PowerPC core, optimized for DeltaV real-time control scanPower input: 5VDC via backplane carrier, max rated current 1.4A, typical power consumption 4.3WOperating ambient: -40℃~+70℃, 5%~95%RH non-condensing; storage temperature -40℃~+85℃Plug-in hot-swap design for standard DeltaV S-series I/O rack; net weight≈0.2kgSupports CHARM electronic marshalling I/O expansion, seamless upgrade from old SD Plus/SQ controller without modifying existing system configuration
Interface & Communication Layout
Dual independent 10/100Mbps full-duplex RJ45 Ethernet (Primary/Security dual network) for DeltaV control network and upper HMI communicationBuilt-in configurable serial bus supporting Modbus RTU for third-party instruments connectionRear gold finger backplane connector for local I/O bus data exchange with rack I/O modulesFront panel LED indicators: RUN, FAULT, NET link status indicator lamps
Core Functions
Execute continuous PID closed-loop control, safety interlock logic, batch recipe control and high-precision SOE event timestamp recordingAuto identify local/remote DeltaV I/O modules, collect analog/digital field signal data and upload real-time parameters to operation workstationSupport redundant pairing installation, bumpless automatic master-slave switching upon primary controller failurePlug-and-play auto network addressing, online program download, parameter modification and full-module self-diagnosis via DeltaV engineering software
Application Scenarios
Petrochemical refining unit control, fine chemical batch reaction workshop, oil & gas terminal process control, thermal power plant water & ash treatment DCS cabinet spare replacement and system upgrade expansion
Operation & Maintenance Notes
Install redundant paired controllers on matched dual-slot dedicated carrier, set different segment IP for dual Ethernet ports to avoid network conflictSeparate Ethernet signal cable from high-power AC power wiring to reduce electromagnetic interferenceRegularly check front panel running indicators; cut off corresponding slot power supply before disassembly and module replacement
