General Information

• Part Number: 0-49008-6

• Manufacturer: Reliance Electric / Rockwell Automation (now ABB)

• Product Type: CardPak Timer / Time Delay Module

• Application: Reliance CardPak racks, FlexPak / MinPak DC drives, industrial control panels

• Status: Obsolete legacy module; available as new surplus, rebuilt, or refurbished

Functional Description

• Precision time-delay / timing control for DC drive systems

• Generates adjustable delay intervals for sequencing, interlocks, and protective logic

• Works in conjunction with other CardPak modules (power supply, linear voltage, etc.)

• Plug-in replacement for time-based control in legacy Reliance drives

Electrical Specifications (typical)

• Input Voltage: +24 VDC (from CardPak power supply, e.g., 0-49001-9)

• Timing Range: Adjustable (seconds to minutes, model-dependent)

• Output Contact: Relay or open-collector logic (dry contact)

• Accuracy: ±1% of full scale

• Temperature Drift: ±0.05%/°C

• Protection: Overvoltage, reverse polarity, short-circuit

Mechanical Specifications

• Form Factor: CardPak standard plug-in module (slot-mount)

• Dimensions (W×H×D): approx. 120 mm × 220 mm × 35 mm

• Weight: approx. 0.8 kg

• Construction: Metal enclosure, edge connector, conformal coated PCB

• Mounting: CardPak rack slot, edge-connector interface

Environmental Ratings

• Operating Temperature: 0 °C to +55 °C

• Storage Temperature: −40 °C to +70 °C

• Humidity: 5%–95% RH, non-condensing

• Vibration: 1 g (10–100 Hz), industrial grade

Key Features

• CardPak Timing Module: Dedicated for time-delay functions in Reliance DC drives

• Adjustable Timing: Potentiometer or multi-turn trimmer for precise setting

• Isolated Output: Reduces noise, suitable for logic and relay loads

• Direct OEM Replacement: Drop-in for legacy CardPak racks

• Repairable: Typically 1–2 year warranty

Compatibility

• Fits: Reliance CardPak racks, FlexPak DC drives, MinPak DC drives

• Series: 0-49008 (Timer/Time Delay Module)

• Related: 0-49001 (power supplies), 0-49005 (linear voltage), 0-49009 (driver modules)
