General Information

• Part Number: 0-49001-13

• Manufacturer: Reliance Electric / Rockwell Automation

• Product Type: CardPak Power Supply Module

• Application: Reliance CardPak system, engineered DC drives (MinPak/FlexPak series), industrial control cabinets

• Status: Obsolete legacy; available as new surplus, rebuilt, or repaired units

Electrical Specifications

• Input Voltage: 115/230 VAC, 50/60 Hz (switchable)

• Output Voltage: +15 VDC, -15 VDC, +24 VDC (regulated)

• Output Current:

  • ±15 V: 0.5 A each

  • +24 V: 1.0 A

• Regulation: ±0.5% (line and load)

• Ripple: < 50 mV p-p

• Protection: Overvoltage, overcurrent, short-circuit, thermal shutdown

• Isolation: Input-to-output isolation, 1500 Vrms

Mechanical Specifications

• Form Factor: CardPak standard plug-in module (slot-mounted)

• Dimensions (W×H×D): approx. 120 mm × 220 mm × 35 mm

• Weight: approx. 0.8 kg (1.76 lb)

• Construction: Metal enclosure, FR-4 PCB, conformal coated

• Mounting: CardPak rack slot, edge-connector interface

Environmental Ratings

• Operating Temperature: 0 °C to +55 °C

• Storage Temperature: −40 °C to +70 °C

• Humidity: 5%–95% RH, non-condensing

• Vibration: 1 g (10–100 Hz), industrial grade

Key Features

• Dedicated CardPak Power Supply: Designed for Reliance’s CardPak control system

• Multiple Regulated Outputs: ±15 VDC for analog circuits, +24 VDC for logic/relays

• High Noise Immunity: Isolated design minimizes EMI/RFI

• Built-in Protection: Comprehensive fault protection for reliable operation

• Direct OEM Replacement: Fits MinPak and FlexPak DC drives

• Repairable: Typically supported with 1–2 year warranty

Compatibility

• Fits: Reliance CardPak racks, MinPak DC drives, FlexPak DC drives

• Series: 0-49001 series (Power Supply)

  • 0-49001-13: Standard power supply

  • 0-49001-14/15: Variants with different output ratings
