1. General Information

• Model: MPRC086444-005

• Alternative Part No.: 086444-005

• Product Type: Direct Fiber Optic Module / Measurement Process Board

• Manufacturer: ABB

• Origin: Sweden

• Series: MPRC40, AC 800M (PM864 equivalent)

2. Electrical & Interface

• Optical Interface: LC (default), 可选 SC

• Data Rate: Up to 1 Gbps

• Wavelength: 850 nm (多模) / 1300 nm (单模)

• Fiber Type: Multi-mode (MM) / Single-mode (SM)

• Max Distance: 550 m (MM) / 10 km (SM)

• Power Consumption: < 1.5 W

• Logic Levels: 0 ≤ +1 V; 1 = +3.5 V ~ +30 V

• Isolation Voltage: 3750 V

3. I/O & Counter

• Digital Inputs (Counter): 4 channels

• Input Frequency: Max 100 Hz

• Input Impedance: 3 kΩ, 0.5 W

• Resolution: 16-bit (0–65535)

4. Environmental

• Operating Temp: -40 °C ~ +85 °C

• Storage Temp: -55 °C ~ +125 °C

• Humidity: 5%–95% RH, non-condensing

• Certifications: CE, UL, RoHS

5. Mechanical

• Dimensions (H×W×D): 48 × 420 × 160 mm

• Weight: 0.4 kg (0.38 kg typical)

• Mounting: Standard ABB rack, PCB slot mount

6. Applications

• Industrial automation, DCS/PLC systems

• Long-distance, EMI-immune data links

• ABB ACS880 drives, AC 800M controllers
