Mitutoyo 8145150

ABSOLUTE Digimatic Indicator (Flat Back, ID‑C Series)

SPECIFICATIONS

• Model Number: 8145150

• Type: ABSOLUTE Digimatic Indicator, ID‑C Series, flat back

• Range: 0–12.7 mm / 0–0.5 in

• Resolution: 0.001 mm / 0.00005 in

• Accuracy: ±0.003 mm (±0.0001 in) at 20°C

• Repeatability: ≤2 μm

• Hysteresis: ≤2 μm

• Measuring Force: ≤1.5 N

• Encoder Type: ABSOLUTE electrostatic capacitance linear encoder

• Max Response Speed: Unlimited (non‑scanning)

• Display: LCD, 11 mm character height

• Stem Diameter: φ8 mm (ISO/JIS)

• Contact Point: Carbide‑tipped, M2.5×0.45 thread

• Back Style: Flat back

• Protection Class: IP42 (dust and splash resistant)

• Data Output: Digimatic SPC interface

• Power Supply: 1 × SR44 silver oxide battery

• Battery Life: Approx. 5,000–7,000 hours

• Operating Temperature: 0°C to +40°C

• Storage Temperature: −10°C to +50°C

• Dimensions (W×H×D): Approx. 54 × 25 × 115 mm

• Weight: Approx. 170 g

• Standards Compliance: CE, RoHS, JIS B 7533

• Origin: Made in Japan

FEATURES

1. ABSOLUTE encoder – retains position after power‑off; no zero reset required.

2. High precision – 0.001 mm resolution with ±0.003 mm accuracy.

3. Large LCD – 11 mm digits for clear workshop reading.

4. IP42 protection – dust and splash resistant for shop‑floor use.

5. SPC data output – direct connection for QC and statistical analysis.

6. Multi‑function operation – zero set, GO/±NG judgment, reverse counting, auto power‑off, data hold.

7. Flat back – compatible with standard indicator stands and fixtures.
