• Model Number: 5532524 (553-252-4)

• Range: 0–12.7 mm / 0–0.5 in

• Resolution: 0.001 mm / 0.00005 in

• Accuracy: ±0.003 mm (±0.0001 in)

• Repeatability: ≤2 μm

• Hysteresis: ≤2 μm

• Measuring Force: ≤1.5 N

• Encoder Type: ABSOLUTE electrostatic capacitance linear encoder

• Max Response Speed: Unlimited (non‑scanning)

• Display: LCD, 11 mm character height

• Stem Diameter: φ8 mm (ISO/JIS)

• Contact Point: Carbide‑tipped, M2.5×0.45 thread

• Back Type: Flat back

• Protection Level: IP42 (dust/water resistant)

• Data Output: Digimatic SPC (for PC/statistical processing)

• Power Supply: 1×SR44 silver oxide battery

• Battery Life: Approx. 5,000–7,000 hours

• Operating Temperature: 0°C to +40°C

• Storage Temperature: −10°C to +50°C

• Dimensions (W×H×D): Approx. 54 × 25 × 115 mm

• Mass: Approx. 170 g

• Compliance: CE, RoHS, JIS B 7533

• Origin: Made in Japan

FEATURES

1. ABSOLUTE encoder: Retains position after power‑off; no zero reset needed.

2. High precision: 0.001 mm resolution with ±0.003 mm accuracy.

3. Large LCD: 11 mm digits for easy reading in workshop conditions.

4. IP42 protection: Dust and splash resistant for shop‑floor use.

5. SPC output: Direct data transfer for quality control and statistical analysis.

6. Multi‑function: Zero set, GO/±NG judgment, reverse counting, auto power‑off, data hold.

7. Flat back design: Compatible with standard indicator stands and fixtures.
