Specifications

• Model No: 563131

• Type: Absolute electrostatic capacitance linear scale

• Effective Measuring Length: 300 mm

• Resolution: 0.001 mm

• Accuracy (20°C): ±(3 + 3L/1000) μm（L=300 mm）

• Encoder Type: Absolute non-contact capacitance

• Scale Pitch: 20 μm

• Max Response Speed: 60 m/min

• Power Supply: 5 V DC ±5%

• Current Consumption: ≤70 mA

• Standard Cable Length: 2 m

• Protection Grade: IP67 dustproof & waterproof

• Operating Temperature: 0 °C ~ +40 °C

• Storage Temperature: -20 °C ~ +60 °C

• Housing Material: Rigid aluminum alloy

• Compliance: CE, RoHS

Features

• Absolute position memory, no zero reset after power cut

• High anti-interference, stable for harsh workshop environment

• Compact structure, easy rear-hole mounting

• Compatible with Mitutoyo DRO digital display systems

• Excellent wear resistance & long service life
