• Model No: 563052

• Type: Absolute electrostatic capacitance linear scale

• Measuring Length: 1500 mm

• Resolution: 0.001 mm

• Accuracy (20°C): ±(3 + 3L/1000) μm（L=1500 mm）

• Encoder Type: Absolute electrostatic capacitance

• Scale Pitch: 20 μm

• Max. Response Speed: 60 m/min

• Power Supply: 5 V DC ±5%

• Current Consumption: ≤70 mA

• Cable Length: 2 m（standard）

• Protection Class: IP67（dust & water resistant）

• Operating Temp: 0 °C to +40 °C

• Storage Temp: -20 °C to +60 °C

• Material: Aluminum housing

• Compliance: RoHS, CE

Features

• Absolute encoder retains position data after power-off（no reset needed）

• High accuracy & stability for long-length measurement

• IP67 dust/waterproof for harsh workshop environments

• Rigid aluminum housing for durability

• Easy installation with rear mounting holes

• Compatible with Mitutoyo DRO systems

• Long-term reliability for machine tools & automation
