6SM56-L3000 is a permanent magnet synchronous servo motor by Kollmorgen Seidel, Germany.
Description
6SM56-L3000
6SM56-L3000 is a permanent magnet synchronous servo motor by Kollmorgen Seidel, Germany.
1. Main Parameters
Model: 6SM56-L3000
Rated Power: 2.6 kW
Rated Torque: 10 Nm
Rated Speed: 3000 rpm
Standstill Current: 7.6 A
Protection Class: IP65
Insulation Class: F
Flange: 115 mm square (56 frame size)
Shaft: Standard shaft with keyway
Weight: approx. 19.0 kg
Feedback: Integrated hollow‑shaft resolver
2. Model Code Interpretation
6SM: Seidel servo motor series
56: Stator outer diameter 56 mm (frame size)
L: Long frame / high inertia
3000: Rated speed 3000 rpm
3. Typical Applications
Machine tools, CNC axes
Heavy‑duty automation, material handling
Printing, packaging, textile machinery
High‑torque positioning systems
4. Matching Servo Drive
Kollmorgen AKD / AKD2G series servo drives
Also compatible with older S600 / S700 Seidel drives
