BAYLOR 56037,BAYLOR 56038,1320-UE

This BAYLOR 56037,56038 and 1320-UE are control PCB cards for drilling rig drawworks brake control and supervision system. The brake control PCB card executes brake control logic, collects speed and load feedback signals from drawworks sensors. The brake control PCB card manages brake torque regulation and safety interlock protection for oilfield drawworks braking system. The brake control PCB card receives operator command signals and outputs drive signals to hydraulic brake proportional valves. The brake control PCB card is built for heavy vibration and dusty environment on offshore and onshore drilling rigs.

This set of boards delivers real-time brake monitoring and safety protection for drawworks operation. The drawworks interface module has LED status indicators for on-site fault alarm and hardware troubleshooting. The drawworks interface module adopts high grade industrial electronic components for long continuous 24-hour operation. The drawworks interface module uses dedicated rack plug-in installation for matching drawworks control cabinet. The drawworks interface module is widely used in oil & gas drilling rig drawworks brake control systems.

It serves as critical spare control components for drilling rig drawworks system overhaul and retrofit. The BAYLOR drawworks spare board is manufactured to original factory specifications for direct plug-in replacement. The BAYLOR drawworks spare board reduces rig downtime during brake control hardware maintenance and replacement. The BAYLOR drawworks spare board supports simple wiring and fast on-site commissioning. The BAYLOR drawworks spare board is stocked by global oilfield and drilling automation spare parts suppliers.
