CLIPSAL L5512RVF C-BUS 12 CHANNEL VOLTAGE FREE RELAY MODULE

CLIPSAL L5512RVF is a DIN-rail mounted C-Bus 12‑channel voltage‑free relay output module, originally produced by Clipsal (Schneider Electric). This C-Bus relay module provides 12 independent relay dry contact channels, each rated 10A, for remote switching of lighting, fans and auxiliary electrical loads. This C-Bus relay module adopts magnetic latching relay design, supports local manual override buttons on each channel, and dual RJ45 C-Bus communication ports for network daisy‑chain connection. This C-Bus relay module isolates C-Bus control network from high-power load circuits, reducing fault spread risks.

This unit is a vital building automation spare part for commercial building, hotel and legacy industrial lighting control system overhaul. The building automation spare part executes C-Bus scene commands, schedule on/off and interlock logic for multiple lighting circuits. The building automation spare part supports software programmable logic, interlock and power recovery state setting. The building automation spare part can replace faulty relay module to restore intelligent lighting load switching function.

It delivers reliable multi-channel dry contact power switching for C-Bus smart automation systems. The multi-channel dry contact power switching completes load circuit switching triggered by C-Bus network commands or local manual button. The multi-channel dry contact power switching provides isolated voltage-free contacts, compatible with different AC/DC power loads. The multi-channel dry contact power switching records channel status and supports system clock synchronization for timed lighting control.

CLIPSAL L5512RVF belongs to C-Bus series, widely used in commercial buildings, hotel intelligent lighting and industrial auxiliary control cabinets. It is discontinued Schneider Clipsal C-Bus 12‑channel relay output module.
