Deif Multi‑line AGC200 Advanced genset controller

Deif Multi‑line AGC200 is a multi‑functional advanced genset controller from DEIF Multi‑line2 series for single‑unit and multi‑generator power management applicationsparsdynamo.... This advanced genset controller integrates genset automatic start‑stop, mains failure protection, generator synchronisation and load‑sharing functions. The advanced genset controller supports CAN‑bus engine communication (J1939 / MTU MDEC/ADEC), configurable M‑logic custom logic and expandable I/O via external CIO series modulesDEIF. The advanced genset controller features full‑text LCD display, built‑in event logger and multiple communication ports for local commissioning and remote supervision.

Genset automatic control & multi‑unit power management is the core function of Deif Multi‑line AGC200 Advanced genset controller. Genset automatic control & multi‑unit power management executes AMF (Automatic Mains Failure), island mode, peak‑shaving, base‑load and load‑take‑over operating sequences for generator sets. Reliable Genset automatic control & multi‑unit power management performs automatic synchronisation, real‑time active/reactive load sharing for up to 128 parallel gensets, together with bus‑tie breaker control. Configurable Genset automatic control & multi‑unit power management enables user‑defined interlock logic via M‑Logic tool, supporting flexible adaptation for marine, industrial backup and hybrid micro‑grid power systems.

This unit delivers outstanding comprehensive generator & engine protective performance for panel‑mount power‑house environments. comprehensive generator & engine protective performance covers over‑current, over‑/under‑voltage, over‑/under‑frequency, reverse power, overload, engine overspeed, high coolant temperature and low oil‑pressure fault protection. Robust comprehensive generator & engine protective performance provides real‑time clock event recording, alarm logging and hour‑meter counting for equipment maintenance traceability. Complete comprehensive generator & engine protective performance supports USB and CAN‑bus PC connection for parameter setup, firmware upgrade and offline simulation with DEIF configuration software.

Deif Multi‑line AGC200 operates on 12 VDC / 24 VDC supply; supports 1‑/2‑/3‑phase voltage and current measurement. The 240×128 full‑text LCD works within ‑40 °C to +70 °C ambient range. It supports SD‑card logging, Modbus communication and expansion with CIO‑series remote I/O modules. Widely deployed for standby power plants, marine vessel power systems, hospital critical power supply and industrial micro‑grid projects. Note: This controller is phased‑out by DEIF and replaced by AGC150 successor modelDEIF. It serves as an original critical genset control spare unit for DEIF Multi‑line2 power management solutions.
