AVR10D-Q22020 is a Yokogawa High-speed Analog Input Module, applied for CENTUM VP DCS and FIO system. It is used to collect standard analog signals from field instruments, with high precision conversion, electrical isolation and strong anti-interference performance, widely used in power, chemical, petroleum and metallurgy process industries.

Model: AVR10D-Q22020Module Type: High-speed Analog Input ModuleInput Signal: Voltage and current signalSampling Speed: High-speed cycle acquisitionIsolation Structure: Channel to system isolatedInstallation Mode: FIO rack mountingPower Supply: Backplane power supplyOperating Temperature: 0 °C to +55 °CStorage Temperature: -20 °C to +60 °CRelative Humidity: 10% to 90% RH, non-condensingFeature Support: Hot swappable, online replacement without system shutdownDiagnostic Function: Built-in module self-diagnosis and channel fault detection

High precision analog signal acquisition, stable measurement accuracy under industrial environment.Adopt isolation design to effectively prevent field interference from affecting DCS system.Support high-speed data sampling to meet fast loop control requirements.Hot swappable design, convenient for maintenance and module replacement.Integrated self-diagnosis function, easy fault judgment and troubleshooting.Compact structure, compatible with standard Yokogawa FIO installation rack.

AVR10D: High-speed analog input module seriesQ22020: Standard configuration code for channel type, isolation grade and version definition

Field analog signal acquisition for temperature, pressure, flow and liquid level instruments.Used in chemical, power, oil & gas, metallurgy and pharmaceutical automation control system.Suitable for high precision and fast response process monitoring and closed-loop control occasions.
