ALP111-S00
ALP111-S00 is a PROFIBUS‑DP communication module manufactured by Yokogawa Electric Corporation for the CENTUM VP DCS platform. It operates as a PROFIBUS‑DP master, enabling data exchange between the DCS and PROFIBUS‑DP slave devices such as PLCs, drives, and remote I/O. The module is certified for PROFIBUS DP‑V0 and supports high‑speed, isolated communication in process industries including chemical, power, oil and gas, and metallurgy.
Basic Specifications
Model: ALP111-S00
Module Type: PROFIBUS‑DP Communication Module (Master)
Communication Protocol: PROFIBUS DP‑V0 certified
Transmission Standard: EIA‑RS‑485, isolated
Transmission Speed: 9600 bps to 12 Mbps
Max Distance: 1.2 km per segment (at 9600 bps)
Ports: 1 × PROFIBUS‑DP (D‑sub 9‑pin female); 1 × maintenance (D‑sub 9‑pin male, RS‑232C)
Cable: Shielded twisted pair
Power Supply: Backplane power
Max Current Consumption: 0.7 A
Dimensions: 130 mm × 125.5 mm × 32.8 mm
Weight: Approx. 0.4 kg
Mounting: AFV10/30/40, AFF50, ANB10/11, ANR10 racks
Operating Temperature: 0°C to +55°C
Storage Temperature: -20°C to +60°C
Relative Humidity: 10%–90% RH, non‑condensing
Certifications: CE, PROFIBUS Nutzerorganisation e.V.
Main Features
Functions as a PROFIBUS‑DP master for seamless integration with third‑party slave devices.
Supports high‑speed communication up to 12 Mbps for efficient process data exchange.
Isolated RS‑485 interface provides strong noise immunity in industrial environments.
Supports linear/cyclic communication, point‑to‑point and multi‑drop topologies.
Hot‑swappable for maintenance without system shutdown.
Compact rack‑mount design with easy wiring and diagnostic LEDs.
Comprehensive diagnostics for quick troubleshooting and status monitoring.
Model Suffix Explanation
S = Standard type
0 = Non‑explosion proof
0 = Basic configuration
Typical Applications
Connects CENTUM VP DCS to PROFIBUS‑DP slaves (PLCs, motor drives, remote I/O).
Used in chemical plants, power stations, oil refineries, and metallurgical facilities.
Suitable for high‑speed, reliable fieldbus communication in process automation.
Description
ALP111-S00 is a PROFIBUS‑DP communication module manufactured by Yokogawa Electric Corporation for the CENTUM VP DCS platform. It operates as a PROFIBUS‑DP master, enabling data exchange between the DCS and PROFIBUS‑DP slave devices such as PLCs, drives, and remote I/O. The module is certified for PROFIBUS DP‑V0 and supports high‑speed, isolated communication in process industries including chemical, power, oil and gas, and metallurgy.
