FANUC AC Servo Motor A06B-0590-B004#7008 General Description A06B-0590-B004#7008 is a compact high-performance AC servo motor of FANUC standard series, designed for 200V class three-phase industrial control system. This motor adopts permanent magnet synchronous motor structure, equipped with straight shaft with keyway, built-in high precision incremental encoder with special specification #7008 for enhanced anti-interference capability. There is no electromagnetic holding brake on this model, and it adopts natural self cooling mode. Featuring small volume, light weight, low rotor inertia, fast dynamic response and stable running performance, it can adapt to complex electromagnetic interference workshop environment, and is widely used in small and medium CNC machine tools, industrial robots and various automated precision positioning driving equipment. Main Technical Specifications Rated continuous output power is 0.4kW, rated continuous torque 0.59Nm, maximum instantaneous torque 1.8Nm. Rated working speed 3000rpm, maximum speed 3000rpm. Applicable power supply is three-phase 200V AC industrial power grid. Built-in high resolution incremental encoder with #7008 special customized specification, which has stronger electromagnetic shielding and anti-interference ability. The motor shaft is straight shaft with standard keyway structure, without power-off holding brake. Protection grade reaches IP65, which can effectively prevent dust, cooling liquid and oil mist from entering the motor interior. Insulation class adopts F level with excellent high temperature resistance. Cooling mode is natural convection self cooling without external cooling fan. The overall weight of the motor is light, suitable for installation occasions with limited space and light load driving requirements. Product Features Compact and lightweight integrated structure saves installation space and reduces mechanical assembly load. Low inertia rotor design realizes rapid acceleration and deceleration response, suitable for high speed and high dynamic motion control occasions. Optimized internal magnetic circuit design ensures smooth rotation operation, low running noise and small vibration amplitude. IP65 fully sealed structure adapts to harsh industrial environment such as dust, water splash and oil mist. Encoder with #7008 special specification enhances anti-electromagnetic interference performance, ensuring stable position and speed feedback signal in complex workshop environment. Straight shaft with keyway structure is convenient for coupling installation and torque transmission. Natural cooling structure is simple and reliable, reducing later maintenance workload. Good compatibility with FANUC mainstream CNC system and supporting servo amplifier, plug and play with stable matching performance. High precision sealed bearing is adopted to ensure long service life and continuous stable operation. Application Scope Suitable for small CNC lathes, milling machines, drilling and tapping machines and other small and medium-sized machine tool feed axis drive. Applied to light duty industrial robot arms, SCARA robots and automated manipulator joint drive. Used in packaging machinery, electronic production assembly equipment, logistics handling automation line positioning axis. Matched for laser processing equipment, precision motion platform, testing instrument and special purpose automation machinery. Ideal for all kinds of light load, high speed, high precision and strong anti-interference required industrial motion control occasions. Installation Instructions Install the motor on a rigid and flat mounting base to avoid working resonance and shaft vibration. Keep the mounting surface clean, flat and free of sundries, deformation and burrs. Align the motor shaft center with the driven load equipment to ensure good coaxiality, and use standard flexible coupling to compensate small installation deviation. Tighten the mounting flange bolts evenly with standard torque to prevent motor shell deformation and internal component stress. Reserve enough space around the motor for natural air circulation heat dissipation and daily maintenance operation. Do not block the motor surface heat dissipation area to avoid poor heat dissipation and abnormal temperature rise. Wiring Requirements All wiring and connection operations must be carried out under complete power cut off condition. Use original FANUC matched power cable, encoder signal cable and grounding wire. Firmly connect the three-phase power line and protective grounding terminal to ensure reliable grounding performance. During wiring layout, separate encoder signal cable from main power cable to avoid electromagnetic interference affecting signal accuracy. All wiring terminals shall be fastened tightly with good insulation performance to prevent short circuit and poor contact. Strictly follow FANUC official standard wiring specifications for wiring connection, do not change the wiring sequence at will. Working Environment The allowable operating ambient temperature is from 0 degrees Celsius to 40 degrees Celsius. Storage ambient temperature ranges from minus 20 degrees Celsius to 60 degrees Celsius. Working relative humidity is 5% to 80%, and condensation phenomenon is not allowed inside and outside the motor. Working altitude shall not exceed 1000 meters above sea level. The surrounding atmosphere shall not contain corrosive gas, flammable explosive dust and excessive oil mist pollution. Avoid long-term exposure to strong mechanical vibration and impact environment. Operation Guidelines The motor must be operated strictly within the rated voltage, torque and speed range, and long-term overload operation is prohibited. After installation and wiring, perform no-load trial operation to check for abnormal noise, vibration and excessive temperature rise. Monitor the motor shell temperature during long-term operation to keep it within the allowable range. Avoid excessive frequent start and stop cycles to prevent motor overheating and mechanical wear and tear. Set the servo amplifier operation parameters reasonably according to the actual motor model and load working condition. Ensure the motor runs within the normal temperature and load range all the time. Maintenance Instructions Regularly cut off the power supply, clean the dust and oil dirt on the motor surface and shell. Periodically check the tightness of mounting bolts, coupling connection and encoder connector plug. Listen to the running sound regularly to judge the working state of internal bearings, and replace bearings in time if abnormal noise occurs. Use CNC system diagnostic function regularly to detect encoder signal quality and positioning stability. It is prohibited to disassemble the motor and encoder privately without authorization, otherwise the precision components will be damaged and the product warranty will be invalid. Keep the motor surface clean and heat dissipation channel unobstructed to ensure long-term stable operation. Safety Precautions Only professionally qualified technical personnel are allowed to carry out installation, wiring and maintenance work of the servo motor. Cut off all input power before maintenance and inspection, and wait for the internal capacitor to complete discharge before operation. It is strictly prohibited to touch the rotating shaft and live electrical parts during motor operation. Must do reliable grounding installation to prevent electric shock accident and reduce electromagnetic interference. Do not arbitrarily modify the internal structure, circuit and encoder configuration of the motor. Keep the motor and matching cables away from flammable materials and high temperature heat source environment.
