A06B-0235-B605#S000
FANUC AC Servo Motor A06B-0235-B605#S000
General Description
A06B-0235-B605#S000 is a FANUC Alpha i series AC servo motor, standard model AiS8/4000. It is designed with tapered shaft, built-in 90V DC electromagnetic brake and high precision resolver encoder. The special suffix #S000 indicates special specification version for machine tool special matching, applied to CNC machine tools and automation vertical axis which need power-off position holding.
Description
Main Specifications
Rated power 2.5kWRated torque 8NmRated speed 4000rpmThree-phase input voltage 200-240V ACShaft form tapered shaftBuilt-in 90V DC holding brakeProtection grade IP65High precision built-in encoderMotor weight about 10kg#S000 special custom specification configuration
Product Features
Compact body with high torque densitySmooth operation, low noise and low vibrationBuilt-in 90V brake ensures safe position locking after power off#S000 special version meets special mechanical installation and matching requirementsIndustrial rugged structure suitable for long-term continuous operationCompatible with FANUC 0i, 30i series CNC servo control system
Application Range
CNC machining center, lathe, grinding machine vertical axisAutomation lifting mechanism and anti-fall positioning axisSpecial machine tool and customized automation equipmentIndustrial servo positioning occasion with brake and special specification requirement
Installation and Operation Notes
Install on rigid fixed base to reduce running vibrationWire power cable, encoder cable and brake cable in accordance with FANUC standardWorking ambient temperature 0℃ to 40℃, keep dry and non-condensingDo not run over speed or over load beyond rated parametersRegularly check motor bearing, encoder signal and brake performance
