9200-00097 (PR9376/010-011) is an EPRO (Emerson) speed / proximity sensor, used for monitoring the rotational speed, key signal and clearance of rotating machinery.

Model Description

9200-00097: Complete Order Number

PR9376/010-011: Product Model

PR9376: Series Name

010: Standard Sensitivity

011: Standard Cable Length and Connector

Core parameters

Measurement principle: Hall effect (differential half-bridge)

Functions: Speed measurement, phase detection, gear/blade count, proximity/gap measurement

Output signal: Square wave pulse (corresponding to rotational speed)

Power supply: +5 to +30 VDC

Frequency range: 0 - 20 kHz

Sensitivity: 10 mV/Gauss

Probe material: Stainless steel (waterproof and dustproof)

Cable length: Standard 10m (Customizable)

Operating temperature: -25℃ to +85℃

Protection level: IP67

Support and Application

Complementary modules: MMS6120, MMS3120 (9100-03047-01), etc.

Typical application: Speed monitoring / phase synchronization for steam turbines, compressors, fans, and pumps
