Model Description

9100-00001-06

9100: EPRO Passive Magnetic Resonance Speed Measurement / Phase Alignment Sensor Series

00001: Standard Body Specification

06: Cable Length 6 Meters

Core Parameters

Working Principle: Passive Magnetic Induction Type, No Power Supply Required

Applicable Objects: Gear Teeth, Phase Alignment Grooves, Ferromagnetic Protuberances

Applicable Speed Range: 0 - 30000 rpm

Frequency Response: 0 - 10 kHz

Recommended Installation Gap: 0.5 - 1.5 mm, Optimal 1.0 mm

DC Resistance of Coil: 200 - 250 Ω (Normal Temperature)

Output: Inductive Sine Pulse Voltage, Changes with Speed and Gap

Probe Installation Thread: M16×1

Cable: 6 Meters Double-Layer Shielded Oil-Resistant Cable

Operating Temperature: -20℃ - +85℃

Protection Grade: IP67

Applicable Teeth Disk: Module m ≥ 2 Ferromagnetic Material Teeth Disk

Connection method

Two-wire passive output:

Signal line 1, Signal line 2

Shielding layer: Only single-point grounding on the control cabinet side, the probe end is left floating

Installation and commissioning key points

The probe should be vertically aligned with the top of the speed measuring gear disk, centered and aligned

The installation gap should be controlled within 0.8 - 1.2mm for the best result

The cable should be kept away from the power cable and the frequency converter to avoid parallel and co-located laying

Compatible accessory modules: MMS6120, MMS6312, etc. for speed / phase matching modules Application scenario

Steam turbines, compressors, fans, gas turbines

Used for speed measurement, zero-speed monitoring, and phase angle acquisition
