5CAMPH.0150-00 Unterminated Hybrid Drag-Chain Cable for Mobile HMI Display System Product Description

The 5CAMPH.0150-00 is original B&R open-end unfinished hybrid drag-chain cable belonging to the standard 5CAMPH product family, specially designed for MP40, MP50, MP7100 and MP7200 series suspended mobile touch display panels of B&R mobile HMI control system, serving as customized field wiring carrier between handheld display terminal and cabinet-mounted 4MPCBX junction box. Distinct from factory pre-assembled finished cables with fixed push-pull and RJ45 plugs such as 5CAMPH.0018-30 and 5CAMPH.0050-30, this 15-meter specification cable is supplied with bare wire ends on both sides without any pre-crimped connectors, reserved for on-site cutting, stripping and personalized terminal assembly to match irregular routing layout of long-distance suspended display arm installation. Developed per Austrian original design specification and IEC global electrical safety standards, the single integrated outer sheath structure fuses multiple functional wire cores inside one cable, unifying 24VDC SELV power feed for display backlight and mainboard operation, shielded Ethernet data transmission for display parameter interaction, independent emergency stop and enable safety signal wiring required by mobile display safety circuit. All raw cables complete factory continuity inspection, AC high voltage insulation withstand testing and multilayer shielding attenuation verification; halogen-free flame-retardant PUR outer casing is optimized for cyclic reciprocating bending inside equipment drag chain, effectively isolating strong electromagnetic interference generated by on-site servo drives and inverters to guarantee continuous stable operation of mobile display system under long-term dragging working environment.

Fixed official ordering part number is 5CAMPH.0150-00 with standard nominal overall length of 15 meters and length tolerance controlled within ±120mm; outer sheath adopts industry standard RAL7012 grey color, with continuous permanent laser printing of part number and production batch code along cable outer surface for spare part identification and after-sales maintenance traceability. Internal conductor uses ultra-fine stranded tinned copper, total 25-core internal wiring divided into four mutually independent functional core groups: three-core plus grounding wire for 24VDC safety extra-low voltage power supply to sustain mobile display screen lighting and internal circuit power consumption, four-core individually shielded star-quad Ethernet twisted pair supporting 10/100Mbps TCP/IP communication for real-time data exchange between cabinet PLC and field touch display, separate four-core emergency stop hard wiring and another four-core enable control signal wire for display safety interlock loop, plus multiple spare auxiliary cores reserved for later display function expansion and on-site debugging wiring. The cable complies with IEC60332-1 vertical flame retardant standard and VDE industrial oil resistance certification, capable of resisting workshop cutting oil mist, mechanical lubricant and mild volatile chemical corrosion. Standard delivery only includes full-length bare-end raw cable without any matching circular push-pull plug, RJ45 modular connector and terminal accessories; matched 4MPCBX junction box, drag chain fixing buckles and wire protection sleeves are not contained in original packaging and need separate procurement according to project actual wiring plan. Unique fixed core arrangement and core color marking make this dedicated hybrid cable unable to be replaced by ordinary separated power cord or commercial grade network wire.

Positioned as long-distance customizable raw connecting cable for B&R suspended mobile touch display system, 5CAMPH.0150-00 targets automation production line long-span suspended display arm layout scenarios where fixed-length pre-terminated finished cables cannot meet variable wiring distance and personalized connector configuration requirements.

The integrated power supply function supports on-site free wiring of 24VDC power circuit from cabinet junction box to mobile display mainboard, maintaining stable screen backlight, touch detection and onboard control circuit continuous operation; anti-fatigue fine-stranded copper wire design reduces core breakage risk caused by repeated drag bending to avoid sudden display blackout or abnormal shutdown induced by internal short circuit. Flexible customized Ethernet communication allows users to install RJ45 plugs arbitrarily at either cable end as needed, establishing direct point-to-point network channel between host PLC and mobile display without intermediate switching equipment, realizing online program download, real-time production data upload and remote configuration modification for touch display system. Independent separated safety signal cores achieve isolated hardwire transmission of emergency stop and enable signals for display safety button; after on-site wiring completion, once the emergency stop key on mobile display is triggered, the signal can be instantly fed back to main control unit to execute rapid equipment safety stop action. Double-layer shielding composed of single-pair independent shielding and overall copper braided shielding suppresses crosstalk between power cores and high-speed communication lines, reducing display screen flicker, data packet loss and accidental false safety triggering under complicated industrial electromagnetic field.

In electrical performance, rated working voltage of internal power conductors is 30VDC conforming to global SELV safety specification; overall shielding attenuation index satisfies IEC60096 standard to keep consistent anti-interference capability during long-cycle bending movement. Core insulation material passes strict AC high voltage withstand testing to prevent insulation breakdown from instantaneous power grid surge and field transient overvoltage fluctuation.

For mechanical performance, minimum dynamic bending radius for drag chain installation is 40mm to adapt frequent reciprocating bending of long-distance suspended display suspension arm; maximum allowable instantaneous pull force reaches 150N to bear accidental pulling during field wiring construction and equipment overhaul. Average unit weight is about 132 grams per meter for drag chain load calculation and display suspension bracket structural design reference.

Regarding environmental adaptability, applicable working ambient temperature ranges from -25°C to +75°C, adapting closed constant-temperature electrical workshop and semi-open variable-temperature processing site; applicable relative humidity is 5%~95% under non-condensing working condition. Halogen-free PUR outer jacket features outstanding hydrolysis resistance and industrial oil-proof property to prevent outer casing cracking and inner insulation ageing after long-term contact with workshop cutting fluid and mechanical grease residue.

Common optional supporting fittings include compatible 4MPCBX series cabinet junction box, MP series dedicated push-pull circular connector, standard RJ45 crimp plug, drag chain special plastic fixing buckle, abrasion-resistant rubber wire inlet sleeve and anti-friction routing guide ring. Matched junction box serves as fixed terminal distribution component inside control cabinet for finished cable wiring separation; assorted connectors are used for user’s on-site bare core crimp assembly to form complete connecting terminals. Drag chain fasteners and rubber protective sleeves prevent cable outer sheath from scratch and extrusion damage caused by sharp metal drag chain edges during continuous cyclic bending.

Conventional daily maintenance auxiliary supplies contain neutral non-corrosive cleaning liquid and anti-static soft wiping cloth for regular outer sheath decontamination under oily and dusty workshop environment; sharp cutting tools and strong corrosive chemical solvent are forbidden in maintenance process to avoid outer casing rupture and internal core insulation corrosion. Automation system integrators are advised to stock spare raw cables to shorten field wiring construction cycle and implement quick replacement when original cable suffers abrasion or ageing damage.

5CAMPH.0150-00 is fully compatible with full range B&R MP40, MP50, MP7100 and MP7200 suspended mobile touch display panels and matching 4MPCBX junction boxes, acting as core customizable wiring component of long-distance mobile HMI display subsystem.

Typical matched mechanical equipment includes automated component assembly production line, precision electronic processing machinery, food and pharmaceutical packaging equipment, small new energy component assembling workstation and bench auxiliary injection molding machine equipped with long-arm suspended handheld touch display terminal.

In industrial application scope, this 15-meter open-end hybrid cable is widely deployed in automotive spare parts automatic manufacturing, precision electronics production, food packaging processing and miniature new energy assembly industries; customizable on-site termination characteristic optimizes wiring flexibility for long-span suspended display layout and improves long-term stable running reliability of whole mobile display control system.

Whole production flow of 5CAMPH.0150-00 is executed under ISO9001 international quality management system and original Austrian B&R cable manufacturing technical standards; raw copper conductor, insulating compound and PUR outer sheath material are sourced from certified qualified upstream suppliers with batch incoming parameter inspection before formal production. Multi-stage in-process quality control includes stranded wire uniformity detection, insulation thickness calibration, finished cable cyclic bending fatigue ageing test, high voltage withstand verification and core continuity inspection to confirm each finished raw cable meets official design specification before factory delivery.

The product holds valid CE and cULus certification and complies with EU RoHS hazardous substance restriction regulation and EMC electromagnetic compatibility directive to satisfy global equipment export access requirements. Optimized anti-fatigue conductor layout and multilayer shielding structure effectively lower field failure rate under long-term cyclic drag working condition; original manufacturer supplies complete after-sales technical service covering model matching confirmation, on-site wiring guidance and routine field fault troubleshooting consultation. After large-scale practical application on numerous flexible automation projects worldwide, the product gains stable market approval for excellent bending durability and flexible personalized wiring advantage.

Unique valid ordering part number is fixed as 5CAMPH.0150-00, complete accurate part code must be filled on purchase order to avoid wrong delivery of pre-terminated finished cables with fixed connectors and different length specifications. All delivered products are brand-new original genuine B&R goods covered under twelve-month factory warranty calculated starting from customer receiving date.

Standard shipment package only contains full 15-meter open-ended un-terminated hybrid raw cable; matched junction box, all kinds of connectors, drag chain fixing accessories and installation auxiliary parts are excluded from default packing scope and require independent ordering according to personalized project field layout demand. Each delivery batch is attached with complete certification document and detailed packing list with diversified logistics options to guarantee intact cargo transportation without outer sheath extrusion damage during transit. Before final order confirmation, purchasers need to verify matched mobile display panel model and junction box specification with authorized distributor or professional technical engineer to prevent specification mismatch and unnecessary economic loss.
