Product Specification – X20CP1483

1. General Information

• Manufacturer: B&R Industrial Automation

• Part Number: X20CP1483 (also available as X20CP1483-1)

• Product Type: Entry-level CPU Controller Module

• Product Series: X20 System

• Certifications: CE, UKCA, cULus, EAC, ATEX Zone 2

• Product Status: Mainstream, Active

• Protection Class: IP20

2. Product Overview

3. Technical Specifications

3.1 Processor & Memory

• Processor: Intel x86-compatible, 100 MHzB& R Industrial Automation

• Floating Point Unit (FPU): IntegratedB& R Industrial Automation

• Internal RAM:

  • 32 MB SDRAM (for program execution)

  • 128 KB non-volatile SRAM (for retentive user data)

• User Memory:

  • 1x CompactFlash slot (removable application memory, sold separately)

• Real-Time Clock (RTC):

  • Non-volatile (battery-backed)

  • Resolution: 1 second

  • Accuracy: ±10 ppm at 25°CB& R Industrial Automation

• Battery: Integrated backup battery for RTC & retentive SRAM

3.2 Communication Interfaces

• Ethernet (10/100 Mbps): 1 × RJ45 (TCP/IP, Modbus TCP)

• POWERLINK: 1 × RJ45 (V1/V2, hard real-time)

• Serial: 1 × RS232 (for diagnostics/HMI)

• USB: 2 × USB 2.0 (for programming, data transfer)

• Local I/O Bus: X2X Link (high-speed backplane)

• Expansion Slot: 1 × slot for X20IF interface modules (e.g., Profibus, CAN)

3.3 Electrical Characteristics

• Supply Voltage: 24 VDC (-15% / +20%)

• Power Consumption: Approx. 6 W (excl. CF card, interface modules, USB)

• Isolation:

  • CPU / X2X Link: Galvanically isolatedB& R Industrial Automation

  • Communication interfaces: Isolated

• Inrush Current: Limited, protected against reverse polarity

3.4 Mechanical Parameters

• Dimensions (W × H × D): 150 × 99 × 85 mmB& R Industrial Automation

• Weight: Approx. 300 gB& R Industrial Automation

• Mounting: Standard DIN rail (35 mm)

• Cooling: Fanless, passive convection

• Terminals: Included 12-pin X20 terminal blockB& R Industrial Automation

3.5 Environmental Conditions

• Operating Temperature:

  • Horizontal: -25°C to +60°C

  • Vertical: -25°C to +50°C

• Storage Temperature: -40°C to +85°C

• Humidity: 5 – 95% RH, non-condensing

• Vibration/Shock: Complies with IEC 60068

• Flammability: UL 94 V-0

3.6 Status & Diagnostics

• LED Indicators:

  • Power, Run, Error

  • Ethernet, POWERLINK activity

  • CF card access, Battery status

• Diagnostics:

  • Module self-test

  • Overload & over-temperature detectionB& R Industrial Automation

  • Communication link monitoring

  • Comprehensive system diagnosis via Automation Studio

4. Key Features

• Entry-level performance: Cost-effective x86 solution with full PLC capabilitiesB& R Industrial Automation

• Real-time POWERLINK: Onboard port for deterministic industrial communicationB& R Industrial Automation

• Flexible expansion: 1 interface slot for fieldbus (Profibus, CANopen, etc.)

• CompactFlash memory: Removable storage for easy program backup & cloning

• Fanless design: Maintenance-free, high MTBF, dust-resistant

• Wide temp & ATEX: Suitable for harsh and hazardous (Zone 2) environments

• Full X20 support: Directly connects all X20 I/O, logic, and specialty modules

• Software: Fully programmed via B&R Automation Studio (IEC 61131-3)

5. Typical Applications

• Small-to-medium packaging, material handling, and textile machines

• Distributed I/O control with real-time POWERLINK

• Standalone equipment in factory automation

• Hazardous area (Zone 2) small-scale control systems

• Retrofit and upgrade projects requiring cost-effective PLC performance

• Building automation and HVAC control

6. Compatibility

• Base Modules: X20BM01, X20BM11, X20BB80

• I/O Modules: All X20 digital, analog, temperature, and specialty modules

• Interface Modules: X20IF series (Profibus, CAN, RS485, etc.)

• Software: B&R Automation Studio (full version)

7. Delivery Scope

• X20CP1483 CPU module

• 12-pin terminal block (TB12)B& R Industrial Automation

• Interface slot coverB& R Industrial Automation

• X20 end cover plateB& R Industrial Automation

• X20 locking clip (X20AC0SR1)

• User documentation
