Product Description The SR750-P5-G1-S1-HI-A20 is a microprocessor‑based feeder management relay from GE Multilin’s 750/760 series, designed for protection, control, and monitoring of medium‑voltage distribution feeders, lines, and bus sections. It integrates high‑speed protection, precision metering, and rich diagnostics, widely used in utilities and industrial power systems.

Description

Model Interpretation

SR750: 750 series feeder management relay

P5: 5 A phase CT secondary input

G1: 1 A ground/zero‑sequence CT input

S1: Standard sensitivity for ground fault protection

HI: High‑impedance control power (70–265 VAC / 88–300 VDC, 48–62 Hz)

A20: 8 analog outputs (4–20 mA)

Technical Parameters

Input & Power

Phase CT Input: 5 A (standard)

Ground/Zero‑Sequence CT Input: 1 A

VT Input: 60–120 V phase‑neutral

Control Power: 70–265 VAC / 88–300 VDC, 48–62 Hz

Power Consumption: ≤15 VA typical

Protection Functions

Overcurrent: Phase/ground, IEC/ANSI inverse/time‑definite, 0.1–20×In

Ground Fault: Sensitive earth fault (1 A input), restricted earth fault (REF)

Voltage/Frequency: Over/undervoltage, over/underfrequency, loss of voltage

Directional Protection: Directional overcurrent/ground fault (for loop/grid feeders)

Breaker Failure: Local/remote breaker failure protection

Trip Time: ≤15 ms (instantaneous overcurrent); ≤30 ms (ground fault)

I/O & Interfaces

Analog Outputs: 8 × 4–20 mA, isolated, 600 Ω max burden

Digital Inputs: 16 opto‑isolated (dry/wet, ≤1 ms response)

Relay Outputs: 8 Form C (5 A / 250 VAC); 3 dedicated (trip, close, self‑test) + 5 configurable

Communication: RS‑232 (front), RS‑485 (Modbus RTU/DNP3), optional Ethernet (IEC 61850)

Display & User Interface

Display: 40‑character backlit LCD (enhanced)

Indicators: 12 LED (RUN, TRIP, ALARM, FAULT, BREAKER STATUS)

Keypad: Numeric/navigation for local programming; password protection

Mechanical & Environmental

Dimensions: 228.6 mm H × 177.8 mm W × 180.9 mm D (9”×7”×7.125”)

Mounting: Panel mount (19” rack compatible), drawout chassis

Enclosure: Flame‑retardant plastic; IP50 (front), IP20 (overall)

Operating Temp: -40°C to +60°C

Humidity: 5–95% non‑condensing

Certifications: UL, CE, CSA, IEC 60255

Metering & Diagnostics

Metering: 3‑phase current/voltage, power, energy, frequency, PF, demand (0.2% accuracy)

Diagnostics: Event log (1024 events), fault recorder (256‑cycle oscillography)

Breaker Monitoring: Trip count, contact wear, coil current monitoring

Core Functions

Comprehensive Feeder Protection: Fast, selective protection for phase/ground faults in distribution feeders.

Sensitive Ground Fault Detection: 1 A ground input detects high‑impedance faults to reduce unplanned outages.

Wide‑Range HI Power: Compatible with 70–265 VAC / 88–300 VDC for flexible substation integration。

8 Analog Outputs: Isolated 4–20 mA outputs for direct connection to SCADA/DCS。

Advanced Fault Diagnostics: Oscillography and event logs enable root‑cause analysis。

Applications

Power Utilities: Distribution substations, overhead/underground feeders, loop networks

Industrial Plants: Petrochemical, metallurgy, mining, water treatment (MV feeders)

Renewables: Wind/solar farm collector feeders, grid interconnection points

Commercial Buildings: Large‑scale MV distribution systems

Usage & Maintenance

Installation: Panel‑mount; wire CT/VT, HI control power, and communications.

Programming: Use front keypad or EnerVista 750 software via RS‑232/Ethernet.

Configuration: Set CT/VT ratios, protection curves, and I/O mapping.

Maintenance: Inspect terminals annually; update firmware; verify settings after system changes.
