4PP015.C420-36 Industrial Touch Screen
The 4PP015.C420-36 is an original imported integrated industrial touch screen belonging to B&R Power Panel 15 series, manufactured in Austria in compliance with global industrial standards and B&R unified production specifications. It adopts embedded panel mounting design for installation inside industrial control cabinets, integrating a 5.7-inch industrial TFT color LCD display, high-sensitivity touch sensing unit, professional membrane keypad, embedded control system and multi-type communication interfaces. This product combines human-machine interaction and local control functions, serving as a dedicated operation terminal and compact controller for automated machinery and production lines. The front panel features a fully sealed industrial structure with IP65 ingress protection to resist dust and splashing liquid in workshop environments, while the rear side is rated IP20 for basic protection. With excellent vibration resistance, electromagnetic interference immunity and wide temperature adaptability, it can operate continuously and stably in harsh industrial conditions such as oily, dusty and mechanically vibrating workshops. It is widely applied for equipment status monitoring, parameter setting, manual operation and fault alarming, and suits both new equipment assembly and old production line renovation projects.
Description
4PP015.C420-36 Industrial Touch Screen
Product Overview
The 4PP015.C420-36 is an original imported integrated industrial touch screen belonging to B&R Power Panel 15 series, manufactured in Austria in compliance with global industrial standards and B&R unified production specifications. It adopts embedded panel mounting design for installation inside industrial control cabinets, integrating a 5.7-inch industrial TFT color LCD display, high-sensitivity touch sensing unit, professional membrane keypad, embedded control system and multi-type communication interfaces. This product combines human-machine interaction and local control functions, serving as a dedicated operation terminal and compact controller for automated machinery and production lines. The front panel features a fully sealed industrial structure with IP65 ingress protection to resist dust and splashing liquid in workshop environments, while the rear side is rated IP20 for basic protection. With excellent vibration resistance, electromagnetic interference immunity and wide temperature adaptability, it can operate continuously and stably in harsh industrial conditions such as oily, dusty and mechanically vibrating workshops. It is widely applied for equipment status monitoring, parameter setting, manual operation and fault alarming, and suits both new equipment assembly and old production line renovation projects.
Basic Information
The official model is 4PP015.C420-36, a genuine imported product produced strictly in accordance with IEC international industrial electronic norms and B&R manufacturing standards. The main body is made of flame-retardant industrial composite materials and internal metal reinforcing frames, which enhance structural rigidity, impact resistance, corrosion resistance and anti-aging performance. The compact overall dimension is optimized for standard cabinet embedding, bringing convenience to on-site installation and daily maintenance.
Equipped with a high-brightness industrial TFT color LCD and a complete membrane keypad including multiple customizable function keys with LED indicators, the device delivers vivid color display and flexible physical operation modes. It is configured with 300 KB SRAM and 1024 KB FlashPROM, providing sufficient storage space for user programs, process data and system configuration parameters. A built-in real-time clock module can accurately record timestamps for production logs and fault records. In terms of I/O resources, the unit integrates 8 channels of 24 VDC digital inputs, 8 channels of 24 VDC digital outputs, 4 channels of analog inputs and 4 channels of analog outputs with 12-bit resolution, supporting multiple signal collection and control requirements and allowing direct connection with on-site sensors, actuators and analog devices.
For communication, it is fitted with one electrically isolated CAN bus interface and one RS232 serial interface, realizing stable data interaction with PLCs, servo drives and upper computer systems. The rated working voltage is 24 VDC, and the internal power circuit is equipped with comprehensive protection mechanisms against overvoltage, undervoltage, reverse polarity, overcurrent and short circuit to safeguard internal hardware. Each finished product undergoes complete functional testing, color display calibration, touch and keypad inspection, sealing test and continuous burn-in aging test before delivery. It has obtained CE certification and complies with EU industrial safety and electromagnetic compatibility regulations. The standardized modular design simplifies wiring, troubleshooting and component replacement.
Function and Positioning
As a dual-functional imported on-site terminal integrating color display, touch operation and localized control, the 4PP015.C420-36 undertakes core tasks including visualized data display, manual operation, logic control, multi-type signal acquisition and data transmission.
In human-machine interaction, the TFT color LCD presents equipment operating parameters, dynamic process flow charts, production data and alarm information with rich colors and clear hierarchy, ensuring excellent viewing effect under both strong light and dim workshop conditions. The combined operation of touch screen and membrane keypad allows operators to efficiently complete interface switching, parameter modification, function selection and equipment start-stop commands. This device can operate independently as a compact controller for small and medium-sized mechanical equipment, or serve as a distributed local operation node in large-scale automated production systems to cooperate with the central control system for partitioned equipment management.
Through CAN bus and RS232 interfaces, the terminal achieves bidirectional data transmission with peripheral automation devices. It uploads on-site collected digital and analog data to the upper management system and downloads control instructions to field actuators. The integrated structure reduces the number of discrete components and intermediate wiring, simplifies the overall system layout, and effectively cuts down equipment assembly and maintenance costs. It is a cost-effective and high-reliability front-end interaction component for compact industrial automation solutions that require both digital and analog signal processing.
Core Performance Parameters
In terms of display and operation performance, the 5.7-inch industrial TFT color LCD maintains stable backlight brightness and consistent color reproduction after long-hour continuous power-on, with a wide viewing angle to ensure clear visibility from different directions. The membrane keypad features comfortable tactile feedback, outstanding wear resistance and long service life, adapting to frequent repeated pressing in industrial environments. Both touch and key responses are sensitive and stable without delay or malfunction.
Regarding electrical performance, the rated input voltage is 24 VDC, with a wide voltage fluctuation tolerance to cope with unstable power supply on industrial sites. All communication circuits adopt galvanic isolation design to suppress electromagnetic interference from motors and frequency converters, guaranteeing accurate and uninterrupted data transmission. Each digital output channel and analog output channel is equipped with independent overcurrent and short-circuit protection to prevent hardware damage caused by abnormal loads or wiring faults. The analog input and output units support 12-bit high-precision conversion, ensuring accurate collection and output of analog signals.
For environmental adaptability, the front panel achieves IP65 protection against dust and splashing liquid, and the rear panel is IP20 protected. The rated operating temperature ranges from 0°C to +55°C, and the storage temperature ranges from -20°C to +70°C. It can work reliably under ambient relative humidity of 10% to 90% non-condensing conditions, with good moisture-proof and mildew-proof capabilities. The whole machine passes standard industrial vibration and impact tests, resisting mechanical vibration from running equipment without internal component loosening or display failure. Internal printed circuit boards are coated with conformal coating to further enhance anti-corrosion and anti-aging performance.
General Matching Accessories
To meet the requirements of installation, wiring, debugging and maintenance, the 4PP015.C420-36 is compatible with a full set of standard supporting accessories. For power and signal connection, dedicated 24 VDC terminal blocks and industrial standard cables are required. In workshops with strong electromagnetic interference, shielded cables are recommended for CAN bus and RS232 communication lines to optimize signal transmission stability. For analog signal circuits, shielded twisted-pair cables are suggested to reduce signal interference and ensure analog acquisition accuracy.
Standard installation accessories include fixing screws and sealing gaskets, which are used for panel embedding and gap sealing between the device and the control cabinet. Users can select extended wiring brackets and cable management accessories according to on-site layout to arrange cables neatly and avoid cable pulling and wear during long-term operation.
Program downloading and offline debugging require supporting programming cables and the official B&R Automation Studio configuration software, which are used for HMI screen editing, logic programming and parameter setting. For daily maintenance and repair, original imported spare parts such as replacement keypads, color display screens, touch components and sealing rings are available for quick on-site component replacement. All supporting accessories comply with B&R unified industrial standards, featuring high versatility, easy procurement and convenient assembly.
Applicable Equipment and Fields
This imported integrated color touch screen is widely applied in multiple industrial automation fields that require colorful visualization, touch/key operation, and simultaneous processing of digital and analog signals, covering general machinery manufacturing, automated assembly lines, packaging machinery, textile equipment, food processing machinery, printing machinery, industrial testing instruments and process control equipment. It is especially suitable for scenarios with temperature, pressure, flow and other analog signal monitoring and control demands. The product applies to complete machine configuration of newly built automated equipment as well as technical transformation, maintenance and upgrading of old production lines.
With panel-mounted installation and compact structure, the device can be flexibly deployed on standard industrial control cabinets, independent equipment operation stations and distributed production line nodes. It adapts to conventional workshop environments with dust, moderate humidity and slight mechanical vibration. Whether for single standalone mechanical devices or large-scale multi-node distributed control systems, it can act as a standard on-site operation terminal to improve production efficiency and on-site operation safety.
Certification and Quality Description
The 4PP015.C420-36 is a genuine imported product manufactured under B&R’s comprehensive quality management system and international industrial electrical safety standards. All production procedures including raw material screening, circuit welding, component assembly, color display calibration, touch testing and finished product debugging are carried out in accordance with standardized operation specifications. Core components such as display screens, touch units, keypads, main control chips, communication modules and analog conversion chips are sourced from qualified industrial-grade suppliers to ensure inherent product quality.
Each production batch undergoes sampling tests including high and low temperature cycle tests and vibration durability tests. Every finished product must pass full inspection items such as insulation resistance test, voltage withstand test, operation function test, signal accuracy test and sealing test before delivery. The product holds CE certification and complies with EU and international industrial safety and electromagnetic compatibility norms, supporting use in most regions around the world.
Adopting mature anti-interference, anti-aging and wear-resistant technologies, the whole machine maintains a low failure rate and long service life under standard working conditions. The manufacturer provides a global after-sales service system, covering professional technical consultation, installation guidance, wiring instructions, program debugging, fault diagnosis and long-term maintenance services. Verified by massive global on-site applications, the 4PP015.C420-36 imported touch screen is a reliable choice for industrial automation system configuration and spare parts stocking.
