3IF782.9 aPCI Bus Control Module – Detailed Product Description

1. Product Overview

2. Core Specifications

2.1 Communication Interfaces

• POWERLINK Port: 1 × POWERLINK interface (RJ45 connector), supporting IEEE 802.3-compliant 100 Mbps real-time industrial Ethernet communication; operates as a POWERLINK manager/controller node.

• Protocol Support: POWERLINK V2/V3 (real-time isochronous and asynchronous data exchange), TCP/IP, UDP/IP; compatible with B&R real-time protocols and third-party POWERLINK devices.

• Electrical Isolation: Galvanic isolation between the POWERLINK interface and the System 2005 backplane protects against voltage spikes, ground loops, and EMI/RFI interference.

• Data Buffering: On-board transmit/receive object buffers reduce CPU load and ensure deterministic data transmission for real-time motion control.

• Network Topologies: Supports star, line, and ring topologies; compatible with standard industrial Ethernet switches and POWERLINK hubs.

• Node Capacity: Manages up to 254 POWERLINK slave nodes per network segment, with high-speed cyclic data exchange.

2.2 Mechanical & Environmental

• Form Factor: aPCI plug-in module (single slot), compatible with System 2005 backplanes and B&R Automation PC aPCI slots.

• Protection Class: IP20 (protected against solid objects >12 mm; intended for indoor industrial use).

• Operating Temperature: 0°C to +55°C (standard); extended range -25°C to +60°C available for extreme conditions.

• Storage Temperature: -40°C to +85°C.

• Power Supply: 5 VDC from the System 2005 backplane; power consumption approximately 2.0 W (no external power required).

• Weight: Approximately 0.18 kg.

• Dimensions: Standard System 2005 module size (W 30 mm × H 90 mm × D 84 mm), compatible with 19-inch rack-mount or standalone System 2005 controllers and Automation PCs.

2.3 Compliance & Certification

• Industrial Standards: CE, UL, CSA, and RoHS compliant.

• EMC Performance: Meets IEC 61000-6-2 (industrial immunity) and IEC 61000-6-4 (industrial emission) requirements, ensuring reliable operation in electromagnetically challenging environments.

• POWERLINK Conformance: Certified by the Ethernet POWERLINK Standardization Group (EPSG) for full protocol compliance.

3. Key Features

1. Real-Time POWERLINK Communication: 100 Mbps POWERLINK interface delivers deterministic, low-latency data exchange for high-speed motion control and synchronized I/O.

2. Master/Controller Functionality: Operates as a POWERLINK manager, configuring and managing slave nodes for centralized network control.

3. Electrical Isolation: Isolation between the POWERLINK interface and backplane prevents ground loops and protects against industrial noise, minimizing downtime.

4. On-Board Object Buffers: Dedicated buffers reduce controller workload, improving communication efficiency and ensuring real-time performance for time-critical applications.

5. Rugged Industrial Design: Conformal-coated PCB and vibration-resistant components withstand dust, moisture, and mechanical stress, supporting 24/7 continuous operation.

6. Seamless System Integration: Plug-and-play installation with hot-swap capability; fully compatible with B&R Automation Studio for configuration, diagnostics, and firmware updates.

7. Diagnostic LEDs: Status indicators for power, POWERLINK link, and activity enable quick on-site troubleshooting and network monitoring.

8. Compact Form Factor: Single-slot aPCI design saves valuable rack space, simplifying system layout and reducing hardware costs.

4. Application Scenarios

• Motion Control Systems: Connects System 2005 controllers to servo drives, stepper motors, and encoders via POWERLINK for synchronized multi-axis motion control in packaging, machine tools, and robotics.

• Factory Automation: Manages distributed I/O modules, sensors, and actuators in assembly lines, material handling, and processing machinery for real-time process control.

• High-Speed Data Acquisition: Transfers high-volume real-time process data between controllers and field devices with minimal latency, supporting precision manufacturing and quality control.

• Integrated Industrial Networking: Combines POWERLINK real-time traffic with standard TCP/IP communication for seamless integration into plant-wide Ethernet networks.

• Remote Diagnostics & Maintenance: Enables secure remote access to POWERLINK networks for troubleshooting, firmware updates, and system configuration via Ethernet.

5. Compatibility & Ordering

• Compatible Systems: B&R System 2005 controllers, backplanes, and I/O systems; B&R Automation PC series with aPCI slots.

• Part Number: 3IF782.9 (original B&R part; terminal blocks ordered separately for field wiring if required).

• Warranty: 12 months (original B&R warranty); extended warranty available upon request.
